Lightway 5

Prismatic Opal - Surface Mounted
The Lightway 5 Diamond-like Prism structure provides a superior vertical/horizontal illumination with great glare reduction (UGR<19). This diffuser offers a very high light transmission making it ideal for workstations’ applications: offices, libraries, classrooms, hospitals, etc.
•  Good glare control (UGR<19). Ideal for the workplace.
•  High efficiency luminaire: 70% LOR
•  Homogeneous glare reduction in all C-levels
Build Your Product Spec Sheetdownload
Product Specifications
  • Ambient lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
  • Used in indoor environments, surface mounted on stone, concrete, metal or wood surfaces.
  • Width of 51mm, height of 80mm and length ranging from 300 to 3000mm with an increment of 300mm.
  • Delivered luminous output per meter from 900lm to 3050lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
  • Color rendering index CRI 90+.

Polar Curves
polar_curves
LOR: 62.2%
Section Drawing
section_drawing
