Lightway 6

Asymmetrical lens - Pendant Direct / Indirect
The Lightway 6 Direct/Indirect linear system offers numerous combinations of optics and output options. A well-lit ceiling improves the look of the workspace without having to compromise on the efficiency.
The asymmetrical linear lens, for direct emission, provides homogeneous distribution of light over vertical surfaces while achieving a very high output, making it ideal for high-ceiling lighting applications.
• The flush lens delivers the best wall uniformity. Vertical light uniformity (1:3)
• High output, ideal for vertical surfaces (over 4 meters high lighting applications)
• Wide lateral illumination with minimal cut-off
• 45cm of side walls to minimize unwanted light spillage
Build Your Product Spec Sheetdownload
Product Specifications
  • Washer lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
  • Used in indoor environments, pendant from stone, concrete, metal or wood surfaces.
  • Width of 66mm, height of 103mm and length ranging from 300 to 3000mm with an increment of 300mm.
  • Delivered luminous output per meter from 700lm to 3150lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
  • Color rendering index CRI 90+.

Direct Polar Curves
polar_curves
LOR: 81.1%
Indirect Polar Curves
polar_curves
LOR: 74.8%
Section Drawing
section_drawing

Mounting Ratio
mounting_ratio

Setback from the wall is defined by wall texture and height. Consult factory for optimal setback according to your project conditions.
