Lightway 6

Asymmetrical lens - Recessed With Trim
The Lightway 6 Asymmetrical Linear Lens provides homogeneous distribution of light over vertical surfaces. It achieves a very high output, making it ideal for high-ceiling lighting applications. The light distribution pattern is optimized for use in a wide variety of applications such as retail shelves and display lighting.

•  The flush lens delivers the best wall uniformity. Vertical light uniformity (1:3)
•  High output, ideal for vertical surfaces (over 4 meters high lighting applications)
•  Wide lateral illumination with minimal cut-off
•  Setback ratio (1:4 to 1:6)
•  45cm of side walls to minimize unwanted light spillage
Build Your Product Spec Sheetdownload
Product Specifications
  • Washer lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
  • Used in indoor environments, recessed with trim in gypsum, metal or wood surfaces.
  • Width of 66mm, height of 103mm and length ranging from 300 to 3000mm with an increment of 300mm.
  • Delivered luminous output per meter from 700lm to 3150lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
  • Color rendering index CRI 90+.

Polar Curves
polar_curves
LOR: 81.1%
Section Drawing
section_drawing

Mounting Ratio
mounting_ratio

Setback from the wall is defined by wall texture and height. Consult factory for optimal setback according to your project conditions.
