Lightway 6

Cut-Off Washer - Recessed With Trim
The Lightway 6 Cut-Off Washer marks a breakthrough in wall washing illumination as it offers different outputs with a flawless surface uniformity while blocking the backward and longitudinal light spill. It is glare- and light-pollution free!
The Lightway 6 Cut-Off Washer is designed to be highly configurable and adaptable to a wide variety of commercial and architectural interior lighting applications.

• True wall wash distribution. Vertical light uniformity (1:4)
• Optimized cut-off: blocking the backward and longitudinal light spill (glare-free)
• Homogeneous color mixing within one reflector cell
• Setback ratio of 1:6
• Continuous rows or individual fixtures
• A minimum of 10 cm from side walls to prevent unwanted light spillage
Build Your Product Spec Sheetdownload
Product Specifications
  • Washer lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
  • Used in indoor environments, recessed with trim in gypsum, metal or wood surfaces.
  • Width of 66mm, height of 103mm and length ranging from 300 to 3000mm with an increment of 300mm.
  • Delivered luminous output per meter from 1950lm to 3600lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
  • Color rendering index CRI 90+.

Polar Curves
polar_curves
LOR: 70.76%
Section Drawing
section_drawing

Mounting Ratio
mounting_ratio

Setback from the wall is defined by wall texture and height. Consult factory for optimal setback according to your project conditions.
