Lightway 6
Diamond Prism - Surface Mounted
The Lightway 6 Diamond-like Prism structure provides a superior vertical/horizontal illumination with glare reduction. This diffuser offers a very high light transmission making it ideal for workstations’ applications: offices, libraries, classrooms, hospitals, etc.
- Good glare control (UGR<19 for flux < 1600lm/m). Ideal for the workplace
- High efficiency luminaire: 70% LOR
- Homogeneous glare reduction in all C-levels
Product Specifications
- Ambient lighting product with extruded aluminum body.
- Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
- Used in indoor environments, surface mounted on stone, concrete, metal or wood surfaces.
- Width of 66mm, height of 103mm and length ranging from 300 to 3000mm with an increment of 300mm.
- Delivered luminous output per meter from 900lm to 4100lm.
- Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
- Color rendering index CRI 90+.
Polar Curves
Diamond Prism
Section Drawing
