Lightway 6 - Outdoor

Beam - Inground Shallow
The Lightway 6 Inground beam is developed for beautiful lighting in harsh environmental conditions. Made from extruded aluminum, this IP67 element benefits from a wide variety of outputs.
The Beam compatible with a wide array of beam angles, generating a powerful overall lighting effect.
• Diverse options of beam angles: very narrow, narrow, medium, wide and elliptic
• Delivers High levels of light
Build Your Product Spec Sheetdownload
Product Specifications
  • Ambient lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth and custom colors upon request.
  • Used in outdoor environments, recessed shallow in concrete surface.
  • Width of 90mm, depth of 112mm and length ranging from 300 to 1500mm with an increment of 300mm.
  • Delivered luminous output per meter from 650lm to 3500lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K.
  • Color rendering index CRI 90+.
  • Light emission beam: 8°, 16°, 30°, 45°, 10° x 54° and 15° x 36°.

Polar Curves
polar_curves
Narrow Beam, 8° / LOR: 83%
polar_curves
Narrow Beam, 16° / LOR: 72%
polar_curves
Medium Beam, 30° / LOR: 82%
polar_curves
Wide Beam, 45° / LOR: 65%
polar_curves
Elliptical beam 10° x 54° / LOR: 72%
polar_curves
Elliptical beam 15° x 36° / LOR: 78%
Section Drawing
section_drawing
